Quick Details

  • Type: Spray Booths
  • Power: 14.5KW
  • External Size: 7050*5250*3600MM
  • Internal Size: 6900*3900*2750MM
  • Voltage: 380V/220v/110v
  • Certification: CE
  • No Load Speed: none
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: SKY
  • Model Number: SB-200
  • Baking temperature: 60~80℃
  • Noise: < 80 db
  • Rockwool: 50mm (optional)
  • Walls/Cellings: Panels 75 mm thick
  • Fans kind: centrifugal fans
  • Baking method: Riello diesel burner
  • Diesel Burner: 1 unit
  • Color: Customize
  • Environmental certificate: CE approved
  • Special design: can do all special design according your requirement

Packaging & Delivery

Packaging Details standard export packing 20GP
Delivery Time 3-5 working days against deposit

                    Auto baking oven/ car painting room/ automotive spray booth

Product Description



Dimensions:

Length (mm)

Width (mm)

Height (mm)

Booth Outside

7,050

5,250

3,600

Booth Inside

6,900

3,900

2,750

Entrance Door

Equipped with Handle & Lock

3,000

2,700

Personnel Door

Equipped with Handle & Anti-Explosion Lock

800

2,000



Features:

Total Power 14.5 KW; 380v/3phase/50hz

Noise < 80 db

1. Walls & Ceiling

- Panels 75 mm thick, with foam in the middle and color steel on both sides

2. Basement System

- Metal Pedestal (Galvanized), with Filter Tray* 2rows & Ramps a couple

- Grid Plates (Galvanized)* 2rows

- Diamond Plates (Powder Coated or Galvanized)* 3rows

3. Heating System

- Diesel Burner (Italy RIELLO, G20)* 1unit

- Heating Exchanger (Stainless Steel material)* 1unit

- 5~10 minutes reaching the baking temperature 60~80 degree Celsius

- Cabinet (rock-wool insulation) * 1unit; Air Ducts * 2pcs

4. Filter System

- Primary Filter* 1set, filtering rate > 83%

- Air-Intake Filter* 1set, filtering rate > 97%

- Air-Exhaust Filter* 1set, filtering rate > 70%

5. Air System

- Air-Intake Fans* 2units, Centrifugal Fans with 4 KW motor each

- Air-Exhaust Fan* 1unit, Centrifugal Fans with 4 KW motor

- Air velocity 0.30 m/s

- Cabinet for the fans* 1unit, and Air Ducts* 3pcs, and Air Damper (pneumatic)* 1unit

6. Illumination

- Ceiling Lights * 32pcs, 36w each, with Light Fixtures, anti-explosion design

- Side Lights * 32pcs, 36w each, with Light Fixtures, anti-explosion design

7. Control Panel

- *1unit, including Spray Switch, Baking Switch, Light Switch, Emergency Stop, etc.

** Included

- All Hardware, Fasteners, and Sealants





Packaging & Shipping

Standard package for transportation

Our Services

1. OEM ODM service.



2. Customized service.

   3. One Year Quality warrant service, during the period spare part supplied free

      if you pay for shipping.



   4.Professional team supply service for life long time.

Company Information

YANTAI SKY MACHINERY CO.,LTD is a company making efforts to supply quality garage equipments including Frame Machine, Booth, Heater and Burner, lift, Tire Changer, Wheel Balancer,Wheel Aligner, Decoder, Key Programmer, Oil Drainer, Tools Cabinet,Air Compressor, Jack & Stand, Crane, Pressing Machine etc. Also we could supply parts and accessories for auto repairing shops, such as hydraulic cylinder for lifts, turning plate for wheel aligner, weights for wheel balancer etc.



Our products have been selling to worldwide countries as Canada, U.S, Colombia, U.K, Ireland, Sweden, Poland, Finland, Hungary, Norway, The Netherlands, Deutschland, Denmark,Bolivia, Latvia, Slovenia, UAE, Saudi Arab, Malaysia, Mongolia ,South Africa ec.



From various customers we learnt various experiences in manufacturing applications, and businesses.We have been improved much of the products and are always will to continuously improve.



FAQ

The buyer who likes us may ask:



Q:Who are you? Trade Company or manufacturer?

A: We are manufacturer and we have our own trade company.



Q: When the product can be delivered?

A:  Commonly the lead time will be within 15 days after receiving 30% deposit or L/C,

subject to prior sales.



Q:What’s the Min order to your company?

A:1 set.The sample order, if we have stocks, we will send out the products within 1 week.



Q:What’s the advantage of your company?

A:We have exported our spray booth and service to more than 50 countries./ we have speclized team work for you, you will get our feedback within 12 hours./ Germany and Italian advanced manufacturering technology.
